pylops.optimization.basic.cgls¶
- pylops.optimization.basic.cgls(Op, y, x0=None, niter=10, damp=0.0, tol=0.0001, rtol=0.0, rtol1=0.0, show=False, itershow=(10, 10, 10), callback=None, preallocate=False)[source]¶
Conjugate gradient least squares
Solve an overdetermined system of equations given an operator
Opand datayusing conjugate gradient iterations.- Parameters:
- Op
pylops.LinearOperator Operator to invert of size \([N \times M]\)
- y
numpy.ndarray Data of size \([N \times 1]\)
- x0
numpy.ndarray, optional Initial guess
- niter
int, optional Number of iterations
- damp
float, optional Damping coefficient
- tol
float, optional Absolute tolerance on residual norm. Stops the solver when the residual norm is below this value.
- rtol
float, optional Relative tolerance on residual norm wrt initial residual norm. Stops the solver when the ratio of the current residual norm to the initial residual norm is below this value.
- rtol1
float, optional Relative tolerance on residual norm wrt to data. Stops the solver when the ratio of the current residual norm to the data norm is below this value.
- show
bool, optional Display iterations log
- itershow
tuple, optional Display set log for the first N1 steps, last N2 steps, and every N3 steps in between where N1, N2, N3 are the three element of the list.
- callback
callable, optional Function with signature (
callback(x)) to call after each iteration wherexis the current model vector- preallocate
bool, optional Added in version 2.5.0.
Pre-allocate all variables used by the solver
- Op
- Returns:
- x
numpy.ndarray Estimated model of size \([M \times 1]\)
- istop
int Gives the reason for termination
1means \(\mathbf{x}\) is an approximate solution to \(\mathbf{y} = \mathbf{Op}\,\mathbf{x}\)2means \(\mathbf{x}\) approximately solves the least-squares problem- iit
int Iteration number upon termination
- r1norm
float \(||\mathbf{r}||_2\), where \(\mathbf{r} = \mathbf{y} - \mathbf{Op}\,\mathbf{x}\)
- r2norm
float \(\sqrt{\mathbf{r}^T\mathbf{r} + \epsilon^2 \mathbf{x}^T\mathbf{x}}\). Equal to
r1normif \(\epsilon=0\)- cost
numpy.ndarray, optional History of r1norm through iterations
- x
